What Every Developer Should Know About Database Scalability

What Every Developer Should Know About Database Scalability

1. Database scalability Jonathan Ellis
2. Classic RDBMS persistence Index Data
3. Disk is the new tape* • ~8ms to seek – ~4ms on expensive 15k rpm disks
4. performance What scaling means money
5. Performance • Latency • Throughput
6. Two kinds of operations • Reads • Writes
7. Caching • Memcached • Ehcache • etc cache DB
8. Cache invalidation • Implicit • Explicit
9. Cache set invalidation get_cached_cart(cart=13, offset=10, limit=10) get('cart:13:10:10') ?
10. Set invalidation 2 prefix = get('cart_prefix:13') get(prefix + ':10:10') del('cart_prefix:13') http://www.aminus.org/blogs/index.php/2007/1
11. Replication
12. Types of replication • Master → slave – Master → slave → other slaves • Master ↔ master – multi-master
13. Types of replication 2 • Synchronous • Asynchronous
14. Synchronous • Synchronous = slow(er) • Complexity (e.g. 2pc) • PGCluster • Oracle
15. Asynchronous master/slave • Easiest • Failover • MySQL replication • Slony, Londiste, WAL shipping • Tungsten
16. Asynchronous multi-master • Conflict resolution – O(N3) or O(N2) as you add nodes – http://research.microsoft.com/~gray/replicas.ps • Bucardo • MySQL Cluster
17. Achtung! • Asynchronous replication can lose data if the master fails
18. “Architecture” • Primarily about how you cope with failure scenarios
19. Replication does not scale writes
20. Scaling writes • Partitioning aka sharding – Key / horizontal – Vertical – Directed
21. Partitioning
22. Key based partitioning • PK of “root” table controls destination – e.g. user id • Retains referential integrity
23. Example: blogger.com Users Blogs Comments
24. Example: blogger.com Users Blogs Comments' Comments
25. Vertical partitioning • Tables on separate nodes • Often a table that is too big to keep with the other tables, gets too big for a single node
26. Growing is hard
27. Directed partitioning • Central db that knows what server owns a key • Makes adding machines easier • Single point of failure
28. Partitioning
29. Partitioning with replication
30. What these have in common • Ad hoc • Error-prone • Manpower-intensive
31. To summarize • Scaling reads sucks • Scaling writes sucks more
32. * Distributed databases • Data is automatically partitioned • Transparent to application • Add capacity without downtime • Failure tolerant *Like Bigtable, not Lotus Notes
33. Two famous papers • Bigtable: A distributed storage system for structured data, 2006 • Dynamo: amazon's highly available key- value store, 2007
34. The world doesn't need another half-assed key/value store (See also Olin Shivers' 100% and 80% solutions)
35. Two approaches • Bigtable: “How can we build a distributed database on top of GFS?” • Dynamo: “How can we build a distributed hash table appropriate for the data center?”
36. Bigtable architecture
37. Lookup in Bigtable
38. Dynamo
39. Eventually consistent • Amazon: http://www.allthingsdistributed.com/2008/12 • eBay: http://queue.acm.org/detail.cfm?id=139412
40. Consistency in a BASE world • If W + R > N, you are 100% consistent • W=1, R=N • W=N, R=1 • W=Q, R=Q where Q = N / 2 + 1
41. Cassandra
42. Memtable / SSTable Disk Commit log
43. ColumnFamilies keyA column1 column2 column3 keyC column1 column7 column11 Column Byte[] Name Byte[] Value I64 timestamp
44. LSM write properties • No reads • No seeks • Fast • Atomic within ColumnFamily
45. vs MySQL with 50GB of data • MySQL – ~300ms write – ~350ms read • Cassandra – ~0.12ms write – ~15ms read • Achtung!
46. Classic RDBMS persistence Index Data
47. Questions
